screw compressor

Name: screw compressor
Brand: C S Valves India
Price: 1000000 INR
Availability: InStock

Price 1000000 INR/ Piece

Get a Price/Quote

MOQ : 01 Piece

screw compressor Specification

Theory
Rotary Screw Compressor

Frequency
50Hz/60Hz

Inlet/Outlet
Flanged connection (size varies by model)

Max Suction
Atmospheric

Working Temperature
5C - 45C

Voltage
380V/415V/460V (standard options, customizable)

Noise Level
65 - 78 dB(A) at 1 meter

Speed
1450 - 2800 RPM (based on model & control type)

Fuel Tank Capacity
N/A (Electric pump, no fuel tank)

Features
Energy Efficient, Low Noise, Easy Maintenance, Air/Oil Separator, Fault Display, Emergency Stop

Head Size
N/A for compressors (pressure rating used)

Discharge Pressure
7 - 13 bar

Mounting Type
Floor/Pad Mounted

Control System
PLC-based Intelligent Microprocessor Control

Flow Rate
7 - 50 m3/min (based on model selection)

Material
Powder-coated Steel Housing, Aluminium and Iron Components

Structure
Enclosed, Skid Mounted

Power
30 HP - 100 HP (varies by configuration)

Standard
ISO 1217

Fuel Type
Electric

Pressure
7 - 13 bar (max 16 bar available for select models)

Usage
Industrial Compressed Air Supply

Application
Manufacturing, Automotive, Electronics, Textile, Packaging

Suction Type
Single Stage

Seals Type
Oil-Sealed

Priming
Self-Primed

Pump Type
Rotary Twin Screw

Capacity
7 - 50 m3/min

Start Type
Star-Delta or Soft Starter (for larger models)

Drive Type
Direct Drive / Belt Drive (according to model)

Cooling Method
Air Cooled/Water Cooled (based on variant)

Display
Digital LCD Control Panel

Motor Protection
IP54/IP55

Weight
750-2500 kg (varies by model)

Lubrication
Forced Oil Lubrication

Environment
Suitable for Dusty and Humid Conditions

Service Interval
2000-4000 Hours

About screw compressor

Rotary screw compressors use a positive displacement principle. They feature two interlocking helical screws (rotors) housed in a casing:

Suction: Air enters the compressor and is trapped between the "male" and "female" rotors.
Compression: As the rotors turn, the space between them decreases, forcing the air into a smaller volume and increasing the pressure.
Discharge: The highly pressurized air is pushed out through a discharge valve into a storage tank or directly to tools.

Key Types

Advanced Cooling Options for Maximum Performance

Select between air-cooled or water-cooled variants, depending on your facility requirements and climate. Efficient cooling ensures stable operation and prolonged system life, even during intensive use.

User-Friendly Digital Control and Monitoring

The integrated digital LCD control panel features PLC-based intelligent microprocessor control, providing precise parameter monitoring, fault alerts, and easy-to-understand system data. Operators benefit from streamlined maintenance and quick troubleshooting.

Engineered for Demanding Industrial Environments

Constructed with powder-coated steel housing and aluminium/iron components, this compressor tackles tough, dusty, and humid industrial settings. Protective seals and IP54/IP55-rated motors enhance longevity and operational safety.

FAQ's of screw compressor:

Q: How does the cooling method impact compressor operation in different environments?

A: The option to choose between air-cooled and water-cooled variants enables the compressor to adapt to varying ambient conditions. Air cooling suits open or well-ventilated spaces, while water cooling offers enhanced efficiency in warmer or confined environments.

Q: What motor protection features are provided, and how do they benefit the system?

A: With IP54 or IP55-rated motors, the compressor is protected from dust and water ingress, ensuring reliable performance and reducing the risk of breakdowns in industrial settings.

Q: When should regular maintenance or servicing be scheduled?

A: Service intervals are recommended between 2,000 to 4,000 operating hours, depending on usage and environmental factors. The intelligent control panel signals when maintenance is required, promoting preventive care and minimizing downtime.

Q: Where is this compressor suitable for installation and use?

A: Ideally installed in industrial facilities such as manufacturing units, automotive workshops, textile plants, and packaging operations, it is designed for both dusty and humid environments, being floor or pad-mounted for stability.

Q: What are the operational benefits of the direct drive and belt drive options?

A: Direct drive offers higher efficiency and lower maintenance due to fewer moving parts, making it ideal for continuous operation. Belt drive models provide flexibility in speed adjustments and are typically easier to service.

Q: How does the control system improve compressor usage and safety?

A: The PLC-based intelligent microprocessor control enhances safety and efficiency by displaying operational parameters, indicating faults, and enabling emergency shutdowns, ensuring optimal performance and user confidence.
